Lowbed 2-Axle Technical Specifications; Chassis: High-strength chassis manufactured from ST 52 material using gas welding. King Pin: Made from 42 Cr Mo4 forged steel, mounted with 8 bolts, 2” in diameter, according to SAE standards. Axles: 2 x 12000 kg load capacity drum axle assembly. Sealed bearing system. Brake System: Dual-circuit pneumatic brake valve with load-sensitive regulator (WABCO) EBS Brake System (WABCO) Automatic brake adjustment lever 30mm Service bellows on the front axle, 30x30 Service emergency bellows on the rear axles Footrests: Double-speed mechanical footrests with a load capacity of 24000 kg. Rear Bumper: Rear bumper suitable for version 70/221/AT. Wheel Block: 1 parking block with carriers. Block. Tires and Rims: 8 Pirelli - Lassa brand 235/75 R 17.5 Tubeless tires. 9.25 – 17.5 Plot Rims Paint: The material is cleaned and sandblasted with grit (metal) material. Phosphate coating is applied. Then 2 coats of epoxy primer paint are applied, and the final coat is painted with 2 coats of acrylic paint in the desired color. Electrical Equipment and Lighting: 3 amber colored lamps on the sides Parking lights, license plate light, triangular reflector at the rear. 2 x 7-pin electrical sockets Volume and Empty Weight: Trough Length: 7500 mm Width: 2550-3000 mm Floor Steel: 6 mm patterned sheet metal. Floor Accessories: 8 mm Crossmember.
